9RX 590Tractor
- Engine HP: 649 Max / 590 hp Rated
- AutoTrac™, StarFire™ receiver, and Gen 4 display integrated
- e18™ PowerShift transmission
- 120-inch track spacing option
Features
Expand All
Collapse All
13.6L (827-cu in.) engine
Ultimate Visibility package at night
9RX in transport
Maximizing uptime using connectivity and technology
Ultimate Comfort and Convenience package (shown on 8R Tractor)
Selective control valves (SCVs) on a 9R Tractor
9RX Tractor
9RX with 91.4 cm (18 in.) tracks and 304.8-cm (120-in.) track spacing
Performing daily maintenance tasks
PowerTech™ 13.6L (827-cu in.) engine: real world usability, not just power on paper
13.6L (827-cu in.) engine
The muscle to handle heavy draft disks and rippers, power-hungry air seeders and planters, and large transport loads like grain carts and slurry wagons. The durable design and heavy-duty components you can depend on when you need to get in and get out. All in a Final Tier 4 (FT4) and Stage V compliant package. You get real-world power with the purpose-built 13.6L (827-cu in.) engines from John Deere Power Systems, standard in the 291 to 440 engine kW (390 to 590 engine hp) 9 Series Tractors.
We developed our newest power plant from a clean sheet of paper, starting with stronger castings, beefier bearings, and more robust internal components, all designed to meet the high demands of field operations. We replaced the fuel injectors with a high-pressure common rail (HPCR) fuel system and eliminated the diesel particulate filter (DPF) to boost to fuel efficiency and lower operation and maintenance costs. Integrated coolant and oil passages, along with a new belt-driven water pump, eliminate potential leak points and allow for a less-crowded engine compartment, improving serviceability and reducing debris accumulation.
In redesigning the engine, we also gave it:
- Hydraulic valve lash adjusters to maintain valve-lash settings during engine operation, reduce valve train noise and wear, and allow for greater fuel efficiency.
- A hydraulic fan drive for improved cooling capacity with no required maintenance.
- A new integrated wiring harness design featuring a modular layout for reduced vibration, greater reliability, and easier service and diagnostics.
- A rear gear train that integrates fully into the cast-iron block, reducing tiresome engine noise and improving the durability of the crankshaft damper.
- Combination sensors where possible, meaning fewer sensors, connectors, and wires.
- A powerful engine brake that allows operators to use the engine to control tractor and implement speeds while transporting or traveling downhill, reducing wear on the drivetrain brake components.
It all adds up to:
- 14 percent more power and 11 percent more torque
- 3 percent lower fuel consumption
- 10 percent lighter
- 27 percent reduction in mean repair time and an estimated $8,308 savings in service costs over the life of the engine
13.5L (824-cu in.) engine compared to 13.6L (827-cu in.) engine
| Feature | 13.5L (824-cu in.) engine | 13.6L (827-cu in.) engine |
| Fuel delivery | Electronic unit injectors (EUI) | HPCR |
| Aftertreatment | Two canisters | One canister |
| Valve lash adjustment | Manual | Automatic |
| Engine brake | Not available | Available above 402.7 kW (540 hp) |
| Wire harness | Single harness | Three short harnesses |
| Water pump | Gear driven | Belt driven |
| Gear train | Front mounted | Rear mounted |
| Fan drive | Vari-Cool™ system | Hydraulically driven |
9 Series Visibility packages let you run with confidence, dawn until dusk
Ultimate Visibility package at night
Visibility is more than just lighting. It’s mirrors where you need them, shades for the blinding late-fall and early-spring sun, wipers to help keep all the glass clear, and integrated camera capability right from the factory. The new 9 Series Tractors let you choose the visibility package that best suits your needs – Select, Premium, or Ultimate with 360-degree light-emitting diode (LED) lighting –so you and your operators can run with all-conditions confidence.
| Select | Premium | Ultimate | |
| Lighting | 18 halogen worklights | 18 LED worklights | 24 LED worklights and eight LED convenience lights* |
| Mirrors | Mechanical | Electric and heated | Electric, heated, and telescoping |
| Sunshades | Front | Front, right-hand side, and rear | Front, right-hand side, and rear |
| Wipers | Front and rear | Front, right-hand side, and rear | Front, right-hand side, and rear |
| Cameras | Camera ready | Camera ready | Front and rear integrated cameras |
*Convenience lights illuminate the corners of the cab for easier entry and exit.
In the field or on the road: adjust steering ratio on-the-go with ActiveCommand Steering (ACS™)
9RX in transport
You don’t have to compromise between pinpoint turns in the field and smooth, easy steering during transport – you can have it all with ActiveCommand Steering (ACS), available on all 9R and 9RX Tractors.
ACS lets you choose your steering ratio based on the task at hand. For precise headland maneuvers in the field, choose a tight 3.5 turns lock-to-lock. When you’re done in the field, ACS gives you a full five turns for smoother line-holding during road transport. Variable-effort resistance automatically changes with ground speed; you’ll notice a lighter touch during low-speed, in-field turns, and increased feedback at transport speeds for more comfortable, confident steering over the road. Plus, ACS works seamlessly with AutoTrac™ guidance systems and is compatible with wide and narrow section width tires as well as wide and narrow belts on 9RX models.
The end result? Reduced overall steering effort and fatigue, no drift and no backlash through the hand-wheel, all with the “connected” feel of a traditional steering column system
John Deere integrated solutions: a world of connected technology, right from the factory
Maximizing uptime using connectivity and technology
John Deere makes it easy for you to access an entire suite of connected applications, all designed to help you make the most of every seed, every hour, every gallon, and every bit of machine-related information.
Each 9 Series Tractor comes standard with the John Deere StarFire™ 6000 Integrated Receiver and Generation 4 CommandCenter™ display; there’s no need for setup, installation, or initial global positioning system (GPS) calibration. Integrated AutoTrac™ assisted steering gives you accurate, scalable guidance for low-stress operation in nearly any conditions and can improve field efficiency by 10 percent or more. The 9 Series Tractors also feature standard JDLink™ telematics and users can turn on connectivity in the John Deere Operations Center for anytime, anywhere access to critical machine and field information. And every tractor comes from the factory with John Deere Connected Support™, so you and your dealer can anticipate and address critical system needs.
From here? The sky’s the limit. Choose any of our operation-specific applications to help maximize efficiency and productivity during planting, tillage, or other field activities.
*NOTE: Ordering is temporarily unavailable for the StarFire 6000 Integrated Receiver. John Deere is diligently working to resolve this issue. Please watch the Price Pages and the announcements in the Sales Manual for updates. We apologize for any inconvenience.
 |
 |
 |
| StarFire 6000 Integrated Receiver | AutoTrac | JDLink |
Base equipment:
Optional equipment:
|
Base equipment:
Optional equipment:
|
Base equipment:
|
*Available with Premium Activation 3.0
**Available with Automation Activation 4.0
Work at your best with 9 Series Comfort and Convenience packages
Ultimate Comfort and Convenience package (shown on 8R Tractor)
When you’re spending dozens of hours per week in the cab, a comfortable operating environment isn’t just an option – the right features, in the right places, let you and your operators work at your best, dawn to dusk and beyond.
The 7, 8, and 9 Series Tractors offer three Comfort and Convenience packages to fit your needs: Select, Premium, and Ultimate. But regardless of which package you choose, you’ll still get the John Deere CommandARM™ console that puts critical controls within easy reach. You’ll get all the storage space you need for drinks, meals, and other stowable items. And you’ll have plenty of outlets to keep your electronics powered.
| Comfort and Convenience packages | Select | Premium | Ultimate |
| Seat |
|
|
|
| Infotainment |
|
|
|
| Business band ready | X | X | X |
| Four USB and one 12-V outlet | X | X | X |
| Dual tilt column | X | X | X |
| Footrests | --- | X | X |
| Refrigerator | --- | X | X |
| 120-V/300-W three-prong outlet | --- | X | X |
| Carpeted floor mat | --- | --- | X |
| Leather-wrapped steering wheel | --- | --- | X |
Bluetooth is a trademark of Bluetooth SIG, Inc. XM is a trademark of Sirius XM Radio Inc.
A range of hydraulic options give you the power and flexibility to take on your toughest applications
Selective control valves (SCVs) on a 9R Tractor
Of course, the 9 Series has the hydraulic muscle you need to push, pull, lift, and power your most demanding implements. But thanks to a range of enhancements to the hydraulic system, these tractors can provide that power at lower engine speeds, saving you fuel while still giving your implements the capacity they need. Regardless of model or configuration, the new 9 Series hydraulic system gives you:
- An increase of almost 40 percent in charge pump capacity, from 54-cc to 75-cc, to help maintain a higher flow at lower engine speeds
- A new swash plate angle sensor to monitor hydraulic flow and pressure and adjust engine speed to meet demand
- An integrated hydraulic pump, filter, and priority valve for fewer and shorter lines, reduced pressure loss, fewer flow restrictions, and an extra level of reliability
And if you depend on implements that need continuous hydraulic power, the 9 Series Tractors are available with Intelligent Power Management (IPM). Using dual pumps and advanced sensor and control technology, IPM provides additional engine and hydraulic power for high-demand applications like air seeding up and over hills or through thick, tough soil.
Add in single and dual pump options and a flexible number rear SCVs, and you can configure a powerful, fuel-efficient hydraulic system to meet the demands of your specific operation without paying for capacity you don’t need.
The new 9 Series: Easy to run, easy to maintain
9RX Tractor
When you’re trying to get a field planted before weather moves in, there’s no time to hit a scheduled maintenance interval or get smacked with an unexpected repair. That’s why we designed the 9 Series for maximum reliability and less in-season maintenance.
To start, we simplified as many systems as possible, using components common to other tractor lines and minimizing potential downtime due to parts availability. Then we eliminated as many potential pain points as possible through changes in the cooling, aftertreatment, and diagnostic systems, including:
- Replacing the fan drive system with a maintenance-free hydraulic fan drive
- Streamlining aftertreatment with a single-canister inline system that’s simpler and features fewer parts
- Improving uptime by adding better descriptions to diagnostic codes and offering predictive diagnostics through John Deere Expert Alerts
- A front-left service panel for easier access to engine oil check and fill points;
- Offering a 500-hour oil change interval on the John Deere Power Systems 13.6L (827-cu in.) Final Tier 4 (FT4) engine when using approved John Deere oil and filter (the Cummins® QSX 15-L [915-cu in.] engine has a 400-hour engine oil and filter change interval).
Cummins is a trademark of Cummins, Inc.
Tackle any terrain with a variety of undercarriage configurations
| 9RX Tractor undercarriage configurations | ||||
 |
 |
|||
| Model | Narrow undercarriage | Wide undercarriage | ||
| Track spacing: 203.2 cm (80 in.), 223.5 cm (88 in.), or 304.8 cm (120 in.) |
Track spacing: 223.5 cm (88 in.) or 304.8 cm (120 in.) |
|||
| 45.7-cm (18-in.) tracks | 61-cm (24-in.) tracks | 76.2-cm (30-in.) tracks | 91.4-cm (36-in.) tracks | |
| 9RX 490 | • | • | • | • |
| 9RX 540 | • | • | • | • |
| 9RX 590 | --- | --- | • | • |
| 9RX 640 | --- | --- | • | • |
• Available
--- Not available
John Deere offers a variety of track widths and track spacings to fit the needs of your operation. The narrow undercarriage is great for row crop applications and can be ordered with track spacings of 203.2 cm (80 in.), 223.5 cm (88 in.), or 304.8 cm (120 in.). The wide undercarriage is ideal for tillage and seeding applications and is available with 223.5-cm (88-in.) or 304.8-cm (120-in.) track spacing.
| Application | Narrow undercarriage | Wide undercarriage |
| Primary tillage | Good | Best |
| Secondary tillage | Better | Best |
| Transport | Good | Better |
| Grain cart | Best | Best |
| Nutrient application | Best | Good |
| Row-crop planting | Best | Better |
| Specialty crops in bedded rows | Best | Good |
| Air seeding | Better | Best |
9RX Tractors equipped with 76.2-cm (30-in.) and 91.4-cm (36-in.) tracks can be equipped with industry-exclusive, factory-installed track spacing set at 304.8-cm (120-in).
9RX Tractors equipped with 304.8-cm (120-in.) track spacing provide increased stability, allow producers to operate on 304.8-cm (120-in.) centers for controlled traffic farming, and provide improved track-to-frame clearance for better access to the undercarriage for serviceability and material cleanout. John Deere is the first and only tractor manufacturer to offer a 304.8-cm (120-in.) track spacing option on four-track tractors with 76.2-cm (30-in.) and 91.4-cm (36-in.) tracks up to 462.3 kW (620 hp).
9RX with 91.4 cm (18 in.) tracks and 304.8-cm (120-in.) track spacing
9RX Tractors with 304.8-cm (120-in.) track spacing increase space between the undercarriage and chassis to provide more space for performing daily and routine maintenance tasks.
Performing daily maintenance tasks
Specifications
| Specifications | ||||
|---|---|---|---|---|
| John Deere 9RX 590 Tractor |
Key Specs
| Engine description | John Deere PowerTech™ 13.6L (B20 diesel compatible) | |||
|---|---|---|---|---|
| Engine displacement | 13.6 L 827 cu in. |
|||
| Rated engine power | 434 kW 590 hp |
|||
| Maximum engine power | 477 kW 649 hp |
|||
| Rated PTO power (hp SAE) | 249 kW 335 hp |
|||
| Maximum PTO power | ||||
| Transmission type | John Deere e18™ 18-speed PowerShift™ with Efficiency Manager™: 40 km/h 25 mph |
|||
| Hydraulic pump rated output | Standard: 208 L/min 55 gpm Optional: 416 L/min 110 gpm |
|||
| Rear hitch category (SAE designation) | Category 4N/4 with capacity: 6804 kg 15,000 lb Category 4N/N: 9072 kg 20,000 lb |
|||
| Base machine weight | 25,546 kg 56,320 lb |
Engine specifications
| Description | John Deere PowerTech 13.6L (B20 diesel compatible) | |||
|---|---|---|---|---|
| Engine type | Diesel, inline, 6-cylinder, wet-sleeve cylinder liners with four valves in-head | |||
| Engine family | ||||
| Rated speed | 2100 rpm | |||
| Aspiration | Dual series turbocharger with fixed geometry first stage and wastegated second stage; air-to-air aftercooling and cooled exhaust gas recirculation (EGR) | |||
| Cylinders liners | ||||
| Emission level | Final Tier 4 (FT4) | |||
| After treatment type | Diesel oxidation catalyst (DOC)/selective catalytic reduction (SCR) | |||
| Displacement | 13.6 L 827 cu in. |
Engine performance
| Rated power | 434 kW 590 hp |
|||
|---|---|---|---|---|
| Rated PTO power (hp SAE) | 249 kW 335 hp |
|||
| Maximum PTO power | ||||
| Intelligent Power Management (IPM) | ||||
| Power boost | 10 percent | |||
| Maximum engine power | 477 kW 649 hp |
|||
| Engine peak torque | At 1600 rpm: 2723 Nm 2008 lb-ft | |||
| Drawbar power | ||||
| PTO torque rise | 38 percent | |||
| Fuel injection system and control | ||||
| Air cleaner type |
Transmission
| Type | John Deere e18 18-speed PowerShift with Efficiency Manager: 40 km/h 25 mph |
|||
|---|---|---|---|---|
| Reverser | ||||
| Clutch; wet/dry | ||||
| Creeper |
Hydraulic system
| Type | Closed-center, pressure-and-flow compensated | |||
|---|---|---|---|---|
| Pump rated output | Standard: 208 L/min 55 gpm Optional: 416 L/min 110 gpm |
|||
| Available flow at a single rear SCV | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm 1.9-cm (3/4-in.) couplers: 159 L/min 42 gpm |
|||
| Available flow at front SCVs | ||||
| Number of rear selective control valves (SCVs) | Four to eight factory or field installed Base: four 1.3-cm (1/2-in.) couplers Optional: five to six 1.3-cm (1/2-in.) couplers factory installed Optional: three 1.9-cm (3/4-in.) couplers plus five 1.3-cm (1/2-in.) couplers factory installed |
|||
| Number of mid selective control valves (SCVs) | ||||
| Number of front selective control valves (SCVs) | ||||
| Joystick SCV control | ||||
| Auxiliary hydraulic features | ||||
| SCV control | Electronic |
Rear hitch
| Hitch draft control load sense type | ||||
|---|---|---|---|---|
| Remote control valves available | ||||
| Hitch category (SAE designation) | Category 4N/4 with capacity: 6804 kg 15,000 lb Category 4N/4: 9072 kg 20,000 lb |
|||
| Maximum lift capacity behind lift points | Category 4N/4: 9072 kg 20,000 lb |
|||
| Lift capacity at standard frame | ||||
| Sensing type | Electrohydraulic with draft sensing | |||
| Rear axle differential lock |
Drawbar
| Drawbar category | Category 5 | |||
|---|---|---|---|---|
| Maximum vertical load | 5440 kg 12,000 lb |
Rear power take-off (PTO)
| Type | Independent 44 mm (1.75 in.) 20-spline, 1000 rpm |
|||
|---|---|---|---|---|
| Engine rpm (at rated PTO speeds) | ||||
| Economy PTO speeds | ||||
| Reverse PTO speeds | ||||
| Multispeed PTO option availability | ||||
| Ground speed PTO option availability | ||||
| PTO actuation | Electrohydraulic |
Front hitch
| Category | ||||
|---|---|---|---|---|
| Electric power | ||||
| Standard lift capacity | ||||
| Front power take-off (PTO) | ||||
| PTO speed |
Rear axle
| Type | ||||
|---|---|---|---|---|
| Final drive type | Bull gear and double idler with floating pinion | |||
| Differential controls | ||||
| Axle type | ||||
| Brakes, type and control | ||||
| Rear differential lock | Full-locking electrohydraulic | |||
| Load rating |
Front axle
| Type | ||||
|---|---|---|---|---|
| Front axle differential lock | Full-locking electrohydraulic | |||
| Load rating |
Tires
| Front | ||||
|---|---|---|---|---|
| Rear | ||||
| Wheel tread range | ||||
| Turning radius with brakes | ||||
| Turning radius without brakes | ||||
| Central Tire Inflation System (CTIS) |
Tracks
| Tread spacing | Wide undercarriage: 2218 mm 87 in. 3048 mm 120 in. |
|||
|---|---|---|---|---|
| Drive type | Camso® 3500 and 6500 Ag Series - reinforced drive lug technology | |||
| Track width | Standard: 762 mm 30 in. 914 mm 36 in. |
|||
| Midrollers | Two |
Steering
| Type | Standard: Hydraulic power steering Optional: ActiveCommand Steering (ACS®) |
|---|
Brakes
| Primary brake (foot brake) | ||||
|---|---|---|---|---|
| Secondary brake | ||||
| Park lock | ||||
| MFWD braking | ||||
| Front axle brakes | ||||
| Auxiliary brakes | ||||
| Hydraulic trailer brakes | ||||
| Pneumatic trailer brakes |
Electrical system
| Alternator size | Standard: 250 amp Optional: 330 amp |
|||
|---|---|---|---|---|
| Battery options | 12 V | |||
| Working lights | Standard: 18 halogen Optional: 18 or 24 LED plus 8 LED conveninence lights |
|||
| Type of bulb in headlight (Halogen, Zenon, LED) | Standard: halogen, 65 W Optional: LED |
|||
| Type of bulb in beacon (Halogen, Zenon, LED) | ||||
| dB(A) rating for backup alarm | ||||
| Total cold cranking amps | 3 x 925 CCA Total: 2775 CCA |
Operator station
| Rollover protective structure, OOS | ||||
|---|---|---|---|---|
| Seat | Degree of seat swivel, left hand 25 degree (angle) Degree of seat swivel, right hand 25 degree (angle) Air suspension |
|||
| Cab suspension | Standard | |||
| Instructional seat | Standard | |||
| Display | Standard: Generation 4 4600 CommandCenter™: 25.4 cm 10 in. Optional: Extended monitor |
|||
| Radio | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna Optional: Touchscreen radio |
|||
| Inner cab volume | 3.27 m3 115 cu ft |
|||
| dB(A) rating | ||||
| Cab glass area | 6.64 m2 71.47 sq ft |
|||
| Safety glass rating | ||||
| Front visibility |
Dimensions
| Wheelbase | 4125 mm 162.4 in. |
|||
|---|---|---|---|---|
| Overall width | ||||
| Overall length | Excluding hitch: 8309 mm 327.1 in. Including hitch and coupler: 8545 mm 336.4 in. |
|||
| Overall height | ||||
| Drawbar clearance | 311 mm 12.2 in. |
|||
| Front axle center | ||||
| Approximate shipping weight, Open;Cab | 20,582 kg 45,375 lb |
Weight
| Base machine weight | 20,582 kg 45,375 lb |
|||
|---|---|---|---|---|
| Maximum ballast level | 30,391 kg 67,000 lb |
|||
| Maximum permissible weight |
Capacities
| Crankcase oil volume | 64 L 16.9 U.S. gal. |
|||
|---|---|---|---|---|
| Fuel tank | 1514 L 400 U.S. gal. |
|||
| Diesel exhaust fluid (DEF) tank | 120 L 31.7 U.S. gal. |
|||
| Cooling system | 62 L 16.3 U.S. gal. |
|||
| Transmission-hydraulic system | With 3-point hitch and PTO: 227 L 60 U.S. gal. Without 3-point hitch and PTO: 220 L 58 U.S. gal. |
Serviceability
| Interval for engine oil change | 500 hours | |||
|---|---|---|---|---|
| Interval for hydraulic/transmission oil change | 1500 hours | |||
| Interval for engine coolant change | 6000 hours |
Loaders
| Loader | ||||
|---|---|---|---|---|
| Lift capacity at full height | ||||
| Maximum lift height | ||||
| Leveling type |
Precision AG
| Guidance | Integrated AutoTrac™ | |||
|---|---|---|---|---|
| Telematic | Available with JDLink™ hardware, activations, and Ethernet harnesses (availability dependent upon destination) | |||
| Remote diagnostics | Available with activated JDLink hardware and activations |
Miscellaneous
| AutoTrac ready | ||||
|---|---|---|---|---|
| ISOBUS ready | ||||
| CommandCenter video inputs | ||||
| Immobilizer | ||||
| Side slope rating | ||||
| Uphill/downhill slope rating | ||||
| Country of manufacture | USA |
Additional information
| Date collected | 1 March 2021 |
|---|
Shop and Buy
Maintenance and Support
You May Also Be Interested In
Product features are based on published information at the time of publication. Product features are subject to change without notice. Contact your local John Deere dealer for more information.
