Replacement Parts Guide:
|
|
5E Tractor Replacement Parts
The 5E utility tractor keeps your agriculture running with ease and comfort. John Deere Connected Support prevents downtime and efficiently resolves issues with revolutionary technology based solutions. These replacement parts will help ensure your projects stay on track.
| Reference # | Frequency (Hours) | Part | Part Number | Quantity | Image | Remarks |
|---|---|---|---|---|---|---|
|
1 |
Annually |
Fresh Air Cab Air Filter |
2 |
|
Hydraulic |
|
|
2 |
Annually |
Recirculation Cab Air Filter |
2 |
|
|
|
|
3 |
Every 250 Hours |
Oil Filter |
1 |
|
|
|
|
4 |
Every 250 Hours |
Oil Filter |
2 |
|
Transmission |
|
|
5 |
Every 250 Hours |
Engine Primary Oil Filter |
1 |
|
|
|
|
6 |
Every 250 Hours |
Engine Secondary Oil Filter |
1 |
|
|
|
|
7 |
Annually |
Engine Primary Air Filter |
1 |
|
|
|
|
8 |
Annually |
Engine Secondary Air Filter |
1 |
|
|
|
|
9 |
Every 500 Hours |
Fuel Filter |
1 |
|
|
|
|
10 |
As Required |
Brake Disk |
8 |
|
MFWD |
|
|
11 |
As Required |
Brake Disk |
2 |
|
|
|
|
12 |
As Required |
Clutch Disk |
1 |
|
Mid Duty |
|
|
13 |
As Required |
Clutch Disk |
1 |
|
(PTO)(Z = 13) |
|
|
14 |
As Required |
Clutch Dusk |
1 |
|
(SyncShuttle™) |
|
|
15 |
As Required |
Clutch Disk |
5 |
|
(PTO)(Z = 58) |
|
|
16 |
As Required |
Battery |
1 |
|
|
|
|
17 |
As Required |
Fan Belt Drive |
1 |
|
(LGTH = 1432 mm) |
|
|
18 |
As Required |
Fan Belt Drive |
1 |
|
(LGTH = 1410 mm) |
|
|
19 |
As Required |
Fan Belt Drive |
1 |
|
(LGTH = 1330 mm) |
|
|
20 |
As Required |
Seat Assembly |
1 |
|
(CAB) |
|
|
21 |
As Required |
Seat Assemmbly |
1 |
|
(OOS) |
|
|
22 |
As Required |
Seat Assembly |
1 |
|
(BACK) |
|
|
23 |
As Required |
Seat Assembly |
1 |
|
(BOTTOM) |
|
|
24 |
As Required |
Alternator |
1 |
|
(70 A) |
|
|
25 |
As Required |
Alternator |
1 |
|
(110 A) |
|
|
26 |
As Required |
Axle Tie Rod |
2 |
|
(Tie Rod) (2WD) |
|
|
27 |
As Required |
Axle Tie Rod |
2 |
|
(Ball Joint) (2WD) |
|
|
28 |
As Required |
Axle Tie Rod |
2 |
|
(Tie Rod End) (2WD) |
|
|
29 |
As Required |
Axle Tie Rod |
2 |
|
(Tie Rod) ( - 046496) |
|
|
30 |
As Required |
Axle Tie Rod |
2 |
|
(Ball joint) ( - 046496) |
|
|
31 |
As Required |
Axle Tie Rod |
2 |
|
(Tie Rod End) ( - 046496) |
|
|
32 |
As Required |
Axle Tie Rod |
2 |
|
(Tie Rod)(MFWD) |
|
|
33 |
As Required |
Axle Tie Rod |
2 |
|
(Tie Rod End)(MFWD) |
|
|
34 |
As Required |
Axle Tie Rod |
2 |
|
(Ball Joint)(MFWD) |
Capacities1
| Component | Oil Grade | Part Number | Qty or capacity |
|---|---|---|---|
|
Fuel Tank |
|
68 L (18 gal)(OOS) |
|
|
Engine Oil |
John Deere Plus-50™/Plus-50™ II |
9.5 L (2.5 gal) |
|
|
Coolant |
Cool-Gard™ |
8.5 L (2.2 gal) |
|
|
Transmission (Sync Shuttle) |
John Deere Hy-Gard™ |
38 L (10 gal) |
|
|
Transmission (PowrReverser™) |
John Deere Hy-Gard™ |
43.5 L (11.49 gal) |
|
|
Mechanical Front Wheel Drive (MFWD) Axle Oil |
John Deere Hy-Gard™ |
4.5 L (1.18 gal) |
|
|
Hub oil |
John Deere Hy-Gard™ |
0.8 L (0.21 gal) |
1See operator's manual for recommended oil type and oil viscosities based on operating temperatures.
