The 730D, 735D, and the 740D Draper models can be equipped with an integral, slow-speed transport system.
John Deere value:
Need for a header trailer is eliminated due to dual-front dolly wheel tires with an extendable tongue and two-gauge wheel tires that can carry the complete weight of the draper when in transport
Road transport is expedited because one person can convert the draper from field to transport mode in a few minutes without the use of tools
In field mode, the dual wheels become the left- and right-hand gauge wheels. For transport, the left-hand dual-dolly wheels support one side of the draper frame and the right-hand dual wheels are repositioned to support the right-hand end of the frame.
The transport package includes warning lights, which can be plugged into a seven-way power source for road transport with a 32.2-km/h (20-mph) speed limit for farm equipment transport.
NOTE: The 730D, 735D, and the 740D Drapers are equipped with two ST215/75R14 gauge wheel tires as base equipment and four ST215/75R14 gauge wheels with the low-speed transport option.
All John Deere 700D Drapers include a double-cut knife which features a hydraulic tilt that is controlled from inside the cab. All 10.6-m (35-ft) and 12.1-m (40-ft) draper cutterbars also have knifeback reinforcement straps to strengthen the knifeback.
The 100-mm (4-in.) cutting action produces a cleaner cut versus the tearing effect of shorter-stroke cutting systems. Knife hold-downs are easily adjusted to help maintain harvesting performance.
The cutterbar hydraulic tilt adjusts a full 8 degrees while maintaining excellent visibility to the cutterbar throughout the tilt range. For improved ease of use the optional advanced hydro handle can be configured to control the platform tilt.
A draper feeding option is available for model year 2018 that will be offered for the full 700D Rigid Draper lineup. This option code will include larger top crop augers with the necessary hydraulic components and mounting hardware as well as an improved seal kit to keep the grain in the draper and not left on the ground.
The top crop auger has been increased in size from 304.8 mm to 457.2 mm (12 in. to 18 in.) with deeper auger flighting to give increased control in bushy crop conditions. This results in even feeding to the center feed drum, which creates a smooth transition to the feederhouse. The seal kit for the center feed section has added rubber seals on both sides of the center feed drum, preventing losses from grain falling outside of the center feed drum.
Reel resume and reverse are features on the 700D Drapers. The combine operator can store two different reel positions with one setting for normal conditions and another for down, tangled, short, or leaning crops.
The center feed drum is designed for efficient, consistent feeding of the crop into the combine feederhouse. A feature for 700D Draper Platforms is a feed drum retractable auger finger to improve crop feeding at the corners of the feed drum.
The feed drum protrudes forward from the draper back sheets, improving the crop handoff from the draper side belts and an increase in slip clutch torque of the center feed drum to 1650Nm from 1200Nm allows for increased capacity in tough crop conditions
In some crop conditions, crop can hesitate at the corners of the feed drum and the retractable drum fingers keep the crop moving into the combine.
The unique dual-knife-drive system is timed, creating the smoothest-possible reciprocating knife-drive system currently in the industry. The positive, reliable shaft-driven dual epicyclical in-line knife drives with built-in driveline protection provide operators with the strongest knife-drive system.
Specs & Compare
|Select up to 4 models to compare specifications||
|Type||Straight line knife drive system|
|Knife drive||Base single, optional dual knife (combine use only)
Base dual knife (SPW only or SPW/combine combination use)
|Knife speed||490 cycles/min
|Cutterbar tilt||Base Hydraulic, 9 degrees tilt maximum|
|Number of slats||6 bat poly base
8 bat steel optional (for forage conditions)
|Fingers||Nylon (steel optional, typically used in rice or forage conditions)|
For rice or forage conditions 1,371 mm
|Reel lift||Cylinder stroke 330 mm
Total range 391.5 mm
|Reel fore and aft||Cylinder stroke 359 mm
Total range 620 mm
|Operating speeds||6-54 rpm|
|Operating speeds (54-in. reel)||5-44 rpm|
|Number of slats|
rubber coated polyester with V-Guide tracking
Side belts 1,016 mm
Center belts 1,397 mm
Center belt not included with SPW configuration
|Clean height||25.4 mm
|Operating speed||Side belts: variable up to 223 m/min
Center belts: 212 m/min
Center belt not included with SPW configuration
|Speed control||Hydraulic from cab|
|Center belt reverse||Base; Center belt not included with SPW configuration|
Feed drum not included with SPW configuration
|Feed drum fingers||Steel heavy-duty round 16 mm (0.625 in) diameter with breakaway notch and retainer|
|Number of fingers||18|
|Auger finger platform||Dual chevron, retracting|
|Finger reach||152 mm
|Operating speed||195 rpm|
|Center clean out door||Base|
|Header height sensing on the ground||Base|
|Header height sensing off the ground|
|Type||Optional hydraulic drive|
|Platform length||8.5 m
|Overall operating depth||2.4 m
|Transport width, field position||8.1 m
|Transport width on wheel, less dividers|
|Transport length, hitch extended|
|Approximate weight (slat reel)|
|Approximate weight (pickup reel)||Combine only 2,884 kg
SPW only 2,284 kg
|Approximate weight (with transport)|
|Approximate weight (optional 54-in. reel)||Combine only 2,974 kg
SPW only 2,374 kg
