5 Family Tractors
Manage tractor from anywhere with the help of JDLink™ compatible with 5 Series Tractors. No matter who is running the tractor, operator can view information such as idle time, fuel levels, and machine location. Analyze machine data to help find minor efficiency gains that can make major impacts on operation.
For more information about JDLink and John Deere Operation Center, visit the JohnDeere.com/PrecisionAg
The JDLink M Modem brings you the value of connectivity to machines in your operation regardless of brand, type, or age*. The M modem is easy-to-install and affordable while delivering valuable location information, machine performance and health data. When included with an optional John Deere display, you can also get agronomic (crop) data. All this data and information flows automatically to your John Deere Operations Center™ account where it is recorded and documented allowing you to measure and manage your operation’s activities better with informed data-based decisions.
When you connect your equipment and use the Equipment Mobile application, connected machines will show engine hours, fuel level, DEF level (if equipped), as well as maintenance tracking and alerts. Equipment Mobile will also provide much more information whether your equipment is connected or not such as is parts specific to your serial number, operator’s manuals, and much more!
Availability of the JDLink M Modem varies by country. Machine data detected by the modem varies by manufacturer and model.
If you simply wish to track the location of a machine, you only need battery power to the modem.
To download the FREE Equipment Mobile app, visit your favorite app store or scan the following QR code:
Any size and type of operation will appreciate the features in the Equipment Mobile application. Use the link for help documentation about the application.
A John Deere account is needed to use the Equipment Mobile app. Here’s a great overview of how to do it: How To Create A John Deere Account | John Deere (youtube.com)
Scan this QR code to get started with your John Deere account:
Here is a great overview to help explain what is the right digital tool for each type of customer: Right digital tool, right user (deere.com)
The John Deere Operations Center playlist is a great way to learn about available features on the web and mobile applications.
Pairing a modem to a machine is simple. Your John Deere dealer will put the modem in your John Deere account. The dealer can also complete pairing for you, or you can pair with these simple steps:
For more details and images, please review online help documentation about pairing JDLink modems.
To pair, your machine also needs to be in your John Deere account. There are easy ways to do it, and great help documents to assist:
Premium cab offering
The power you need to tackle tasks around the operation now with a Premium cab option. Starting in Model Year 2024, 5090E and 5100E tractors can be ordered with a Premium cab from the factory that will increase your comfort whether you are working in the field or around your property.
Compare features offered in Standard Cab versus Premium Cab: |
||
Features |
Standard Cab |
Premium Cab |
Sunroof with sunshade |
--- |
Exclusive |
USB and auxiliary audio port |
--- |
Exclusive |
Rear window pull handle |
--- |
Exclusive |
Leather wrapped steering wheel |
--- |
Exclusive |
Instructional seat |
Extra |
X |
Bluetooth radio with microphone |
Extra |
X |
Instructional seat |
Extra |
X |
Bluetooth radio with microphone |
Extra |
X |
Front and rear LED work lights |
Optional |
X |
LED headlights (high and low beam) |
Extra |
X |
Right-hand door and steps |
Extra |
X |
Tilt and telescopic steering column |
X |
X |
Cloth seat with retractable seat belt |
Mechanical seat suspension |
Air ride seat suspension |
Air conditioning and heater |
X |
X |
Convenience power outlet |
X |
X |
LED headlights (high and low beam) |
Extra |
X |
Rear window wiper with washer |
Optional |
X |
Right-hand door and steps |
Field Kit Only |
X |
Cloth seat with retractable seat belt |
Mechanical seat suspension |
Air ride seat suspension |
Tilt and telescopic steering column |
X |
X |
Air conditioning and heater |
X |
X |
Convenience power outlet |
X |
X |
Two rear SCVs |
X |
X |
Three-position (on/off/auto) interior dome light |
X |
X |
Right-hand console ambient lighting |
X |
X |
Beverage holders |
X |
X |
Sun visor |
X |
X |
Rearview mirror |
X |
X |
Two mounting bosses for monitors or accessories on B-pillar |
X |
X |
Radio Preparation (with speakers and wiring) |
X |
X |
Front windshield wiper with washer |
X |
X |
Amp-style, three-socket power connector |
X |
X |
Stationary PTO enable switch |
X |
X |
Leather wrapped steering wheel
Right hand controls
Factory installed Bluetooth® radio
Factory installed instructional seat
Dual rear bale spear
Moving heavy hay bales through the field or using a larger 3-pt mount sprayer is no problem for the 5E tractors. The Model Year 2024 5090E, 5100E, and 5090EL tractors have a rear hitch lift capacity up to 4,600 lbs (2100 kg) which is over 30% more than previous models. Utilizing larger implements while maintaining the durability of the rear hitch can lead to significant efficiency gains on your operation.
Moving 3 bales at once
| Specs & Compare | ||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere 5090EN Tractor |
| Engine description | John Deere PowerTech™ 4045 PWL | |||
|---|---|---|---|---|
| Engine displacement | 4 cylinders: 4.5 L 276 cu in. |
|||
| Rated engine power | At 2400 rpm: 67.1 kW 90 hp |
|||
| Maximum engine power | 68.6 kW 92 hp |
|||
| Rated PTO power (hp SAE) | At 2400 rpm: 56.0 kW 75 hp |
|||
| Maximum PTO power | ||||
| Transmission type | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ Hi-Lo 24F/12R |
|||
| Hydraulic pump rated output | 85.1 L/min 22.5 gpm |
|||
| Rear hitch category (SAE designation) | Category 2 | |||
| Base machine weight | ||||
| Hydraulic Pumps Nominal Flow | ||||
| Maximum PTO power at rated engine speed with intellegent power management (IPM) | ||||
| Maximum engine power (ECE-R120) | ||||
| Maximum engine power PS (hp ISO) at max engine speed (EU 2016/1628) | ||||
| Rated Engine Power (SAE J1995) | ||||
| Rated PTO Power | ||||
| Rated engine power (ECE-R120) | ||||
| Rated engine power PS (hp ISO) at rated engine speed (EU 2016/1628) | ||||
| Rear Hitch Category (ISO 730-2009) |
| Description | John Deere PowerTech 4045 PWL | |||
|---|---|---|---|---|
| Engine type | 4045HLV76 | |||
| Engine family | NJDXL04.5315 | |||
| Rated speed | 2400 rpm | |||
| Aspiration | Turbocharged and Aftercooled | |||
| Cylinders liners | Wet sleeved | |||
| Emission level | Final Tier 4 | |||
| After treatment type | DOC/SCR | |||
| Displacement | 4 cylinders: 4.5 L 276 cu in. |
| Rated power | At 2400 rpm: 67.1 kW 90 hp |
|||
|---|---|---|---|---|
| Rated PTO power (hp SAE) | At 2400 rpm: 56.0 kW 75 hp |
|||
| Maximum PTO power | ||||
| Intelligent Power Management (IPM) | ||||
| Power boost | At 2200 rpm: 2 percent | |||
| Maximum engine power | 68.6 kW 92 hp |
|||
| Engine peak torque | At 1600 rpm: 347 Nm 255 lb-ft |
|||
| Drawbar power | ||||
| PTO torque rise | ||||
| Fuel injection system and control | ||||
| Air cleaner type | ||||
| Maximum Engine Torque | ||||
| Maximum PTO power at rated engine speed with intellegent power management (IPM) | ||||
| Maximum engine torque (without power boost at 1.600 engine rpm) | ||||
| Maximum engine power (ECE-R120) | ||||
| Maximum engine power PS (hp ISO) at max engine speed (EU 2016/1628) | ||||
| Maximum engine power with intelligent power management (IPM) | ||||
| Rated PTO Power | ||||
| Rated engine power PS (hp ISO) at rated engine speed (EU 2016/1628) | ||||
| Rated power (ECE-R120) | ||||
| Torque Reserve |
| Type | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ Hi-Lo 24F/12R |
|||
|---|---|---|---|---|
| Reverser | Yes | |||
| Clutch; wet/dry | Wet | |||
| Creeper | Not available | |||
| Creeper Transmission (Reducer) | ||||
| Integrated Electric Power Generation |
| Type | Open center | |||
|---|---|---|---|---|
| Pump rated output | 85.1 L/min 22.5 gpm |
|||
| Available flow at a single rear SCV | 60.1 L/min 15.9 gpm |
|||
| Available flow at front SCVs | ||||
| Number of rear selective control valves (SCVs) | Standard: Two Optional: Three |
|||
| Number of mid selective control valves (SCVs) | Standard: Zero Optional: Up to Three |
|||
| Number of front selective control valves (SCVs) | ||||
| Joystick SCV control | Mechanical | |||
| Auxiliary hydraulic features | ||||
| SCV control | ||||
| Available oil flow at a single rear SCV (200 Type) | ||||
| Available oil flow at a single rear SCV (450 Type) | ||||
| Available oil flow at a single rear SCV (450E Type) | ||||
| Flow Control Valve | ||||
| Hydraulic Pumps Nominal Flow |
| Hitch draft control load sense type | Mechanical | |||
|---|---|---|---|---|
| Remote control valves available | Standard: Two Optional: Three |
|||
| Hitch category (SAE designation) | Category 2; convertible to 1 | |||
| Maximum lift capacity behind lift points | Standard: 2100 kg 4600 lb |
|||
| Lift capacity at standard frame | ||||
| Sensing type | Top link | |||
| Rear axle differential lock | ||||
| Maximum Lift Capacity (SAE J283) | ||||
| Maximum lift capacity directly at coupling points | ||||
| Maximum lift capacity at coupling points | ||||
| Rear Hitch Category (ISO 730-2009) | ||||
| Rear hitch lift capacity (SAE designation) | ||||
| Throughout lift capacity, 610 mm behind the coupling points |
| Drawbar category | Category 2 | |||
|---|---|---|---|---|
| Maximum vertical load | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg |
| Type | Standard: 540/540E Optional: 540/1000 |
|||
|---|---|---|---|---|
| Engine rpm (at rated PTO speeds) | 540 at 2400 rpm 540E at 1716 rpm 1000 at 2400 rpm |
|||
| Economy PTO speeds | ||||
| Reverse PTO speeds | ||||
| Multispeed PTO option availability | ||||
| Ground speed PTO option availability | ||||
| PTO actuation | Electrohydraulic | |||
| E-PTO (Economy Rear Power Take-Off) | ||||
| Engine rpm at rated PTO speeds (540/1.000) | ||||
| Engine rpm at rated PTO speeds (540/540E/1.000) | ||||
| Engine rpm at rated PTO speeds (540E/1000/1.000E) |
| Category | ||||
|---|---|---|---|---|
| Electric power | ||||
| Standard lift capacity | ||||
| Front power take-off (PTO) | ||||
| PTO speed |
| Type | Flange | |||
|---|---|---|---|---|
| Final drive type | Inboard planetary | |||
| Differential controls | Mechanical (pedal) | |||
| Axle type | ||||
| Brakes, type and control | Hydraulic wet disc | |||
| Rear differential lock | ||||
| Load rating |
| Type | Mechanical Front Wheel Drive (MFWD) | |||
|---|---|---|---|---|
| Front axle differential lock | ||||
| Load rating | ||||
| Seal Type |
| Rear | MFWD: 18.4-30 R1 Bias | |||
|---|---|---|---|---|
| Wheel tread range | MFWD: front: 1340-1904 mm 52.8-75.0 in. |
|||
| Turning radius with brakes | MFWD: 4.36 m 14.3 ft |
|||
| Turning radius without brakes | MFWD: 3.54 m 11.6 ft |
|||
| Central Tire Inflation System (CTIS) | ||||
| Front |
| Tread spacing | ||||
|---|---|---|---|---|
| Drive type | ||||
| Track width | ||||
| Mid-rollers |
| Type |
|---|
| Primary brake (foot brake) | ||||
|---|---|---|---|---|
| Secondary brake | ||||
| Park lock | ||||
| MFWD braking | ||||
| Front axle brakes | ||||
| Auxiliary brakes | ||||
| Hydraulic trailer brakes | ||||
| Pneumatic trailer brakes |
| Alternator size | OOS: 90 amp Cab: 120 amp |
|||
|---|---|---|---|---|
| Battery options | 12 V | |||
| Working lights | Halogen | |||
| Type of bulb in headlight (Halogen, Zenon, LED) | Halogen | |||
| Type of bulb in beacon (Halogen, Zenon, LED) | Kit: Halogen | |||
| dB(A) rating for backup alarm | ||||
| Total cold cranking amps | ||||
| Lighting Type |
| Rollover protective structure, OOS | Rigid - foldable - telescopic Foldable, two-post Platform - flat/straddle Straddle Gearshift location - console/floor Floor |
|||
|---|---|---|---|---|
| Seat | Standard: Mechanical Optional for Cab: Air Ride |
|||
| Cab suspension | ||||
| Instructional seat | Optional for Standard cab Included with Premium cab |
|||
| Display | Automotive-style light-emitting diode (LED) instrument cluster | |||
| Radio | ||||
| Inner cab volume | 78 dBA | |||
| dB(A) rating | ||||
| Cab glass area | ||||
| Safety glass rating | ||||
| Front visibility | ||||
| CAB Type | ||||
| Roll-Over Protective Structure (ROPS) | ||||
| Seat / Suspension |
| Wheelbase | 2350 mm 92.5 in. |
|||
|---|---|---|---|---|
| Overall width | ||||
| Overall length | 4042 mm 159.13 in. |
|||
| Overall height | ||||
| Drawbar clearance | ||||
| Front axle center | ||||
| Approximate shipping weight, Open;Cab | OOS: 3300 kg 7275 lb Cab: 3700 kg 8150 lb |
|||
| Approximate Shipping Weight | ||||
| Turning radius without brakes |
| Base machine weight | ||||
|---|---|---|---|---|
| Maximum ballast level | ||||
| Maximum permissible weight | ||||
| Approximate Shipping Weight | ||||
| Maximum Ballast |
| Crankcase oil volume | ||||
|---|---|---|---|---|
| Fuel tank | OOS: 94.6 L 25 U.S. gal. Cab: 114 L/min 30 U.S. gal. |
|||
| Diesel exhaust fluid (DEF) tank | 12.0 L 3.17 U.S. gal. |
|||
| Cooling system | ||||
| Transmission-hydraulic system |
| Interval for engine oil change | ||||
|---|---|---|---|---|
| Interval for hydraulic/transmission oil change | ||||
| Interval for engine coolant change |
| Loader | ||||
|---|---|---|---|---|
| Lift capacity at full height | ||||
| Maximum lift height | ||||
| Leveling type |
| Guidance | No | |||
|---|---|---|---|---|
| Telematic | JDLink™ | |||
| Remote diagnostics | ||||
| Auto Pilot | ||||
| Connectivity | ||||
| Monitor | ||||
| Receiver |
| AutoTrac ready | No | |||
|---|---|---|---|---|
| ISOBUS ready | No | |||
| CommandCenter video inputs | ||||
| Immobilizer | ||||
| Side slope rating | ||||
| Uphill/downhill slope rating | ||||
| Country of manufacture | Saltillo, Mexico |
| Date collected | 1-Aug-2023 |
|---|
1Activation required. JDLink hardware comes standard with the machine. You can turn on JDLink Connected service in your John Deere Operations Center™ account for free.
JDLink requires a cellular connection to transfer information from machine to a JDLink website. Consult your John Deere dealer for coverage availability.
