Dual element dry canister with external rotary ejector pre-cleaner
Standard eco mode maximizes fuel economy without sacrificing performance, automatically adjusting engine rpm and transmission settings based on load.
Cab-forward design provides excellent visibility to the blade.
Sealed-switch module allows low-effort control of keyless start, and enables exclusive features, such as turbocharger cool-down and auto shutdown.
Hinged engine side shields swing open wide and the front grille tilts forward for convenient access to dipsticks, fill tubes, batteries, master electrical shutoff, the backside of the cooler, and filters.
Infinitely variable range to 11 km/h (6.8 mph) allows total flexibility to match ground speed to the load.
Adjusts speed and power to match changing load conditions
Exclusive safety feature engages wet, multiple-disc brakes whenever the engine stops, the decelerator is depressed to the end of travel, or the park-lock lever is placed in the start or neutral positions and motion is detected.
Grade-control system is fully integrated into the machine cabin, structures, and software – delivering precise grading performance while eliminating vulnerable external masts and cables.
Auto SmartGrade automatically raises the blade when heavier loads are encountered during rough grading to prevent stalling and track slip, enabling the machine to be used in all phases of grading.
Machine dimensions are preloaded into the grade-control monitor, reducing the time needed to calibrate to about 30 minutes.
|Specs & Compare|
|Select up to 4 models to compare specifications||
|Engine Manufacturer||John Deere|
|Engine Model||PowerTech PSS 6090|
|Displacement, ltr (Inches³)||9 (549)|
|Rated Speed, rpm||1800|
|Engine Output - Net, kW (hp)||198 (265)|
|Speeds Mode 1 - Forward||1|
|Speeds Mode 1 - Reverse||1|
|Final Drive||Double Reduction - Planetary|
|Shoe - Pitch, mm (inches)||215.9 (8.5)|
|Shoe - Type||Single Grouser - Extreme Service|
|Ground Contact Area, cm² (Inches²)||39211 (6078)|
|Number Of Shoes||43|
|Height - Max, mm (ft/in)||3427 (11 ft 3 in)|
|Ground Clearance, mm (inches)||312 (12.3)|
|Track Length - On Ground, mm (ft/in)||3214 (10 ft 6 in)|
|Track Gauge, mm (ft/in)||2006.6 (6 ft 7 in)|
|Blade - Width, mm (ft/in)||3911 (12 ft 10 in)|
|Blade - Dig Depth, mm (inches)||778 (31)|
|Blade - Tilt, mm (ft/in)||800 (2 ft 7 in)|
|Steering - Differential||No|
|Fuel Tank, ltr (gallons (US))||505.5 (133.5)|
|Hydraulic Tank, ltr (gallons (US))||87 (23)|
|Blade - Capacity, m³ (yd³)||7.2 (9.4)|
|Speed - Forward Maximum, kph (mph)||11 (6.8)|
|Speed - Reverse Maximum, kph (mph)||11 (6.8)|
|Ground Bearing Pressure, kPa (PSI)||74 (10.8)|
|Implement Pump - Type||Piston Pump|
|Implement Pump - Flow, lt/min (gallons (US) / min)||200 (53)|
|Implement Pump - Pressure, bar (PSI)||249.93 (3625)|
|Operating Weight, kg (lbs)||29606 (65300)|
