5093ENNarrow Series Tractor
Narrow design for vineyard, orchard and nursery producers
Just 45.2 inches (114.8 cm) wide from the outer edges of the rear tires
Available in cab and open station configurations
Choose 2WD or MFWD
Specs & Compare
Add Model
Specs & Compare |
||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere 5093EN Narrow Series Tractor |
Key Specs
| Engine description | John Deere PowerTech | |||
|---|---|---|---|---|
| Engine displacement | 4 cylinders: 4.5 L 276 cu in. |
|||
| Rated engine power | At 2400 per ISO 97/68/EC: 69.3 kW 93 hp |
|||
| Rated PTO power (hp SAE) | At 2400 rpm per SAE: 59 kW 79 hp |
|||
| Maximum PTO power | ||||
| Transmission type | Standard: 12F/12R PowrReverser Optional: 24F/24R PowrReverser |
|||
| Hydraulic pump rated output | 94.6 L/min 25 gpm |
|||
| Rear hitch category (SAE designation) | Category 2/1/1N | |||
| Base machine weight | ||||
| Maximum engine power |
Engine specifications
| Description | John Deere PowerTech | |||
|---|---|---|---|---|
| Engine type | ||||
| Engine family | BJDXL04.5111 | |||
| Rated speed | ||||
| Aspiration | Turbocharged | |||
| Cylinders liners | Sleeved | |||
| Emission level | ||||
| After treatment type | ||||
| Displacement | 4 cylinders: 4.5 L 276 cu in. |
Engine performance
| Rated power | At 2400 per ISO 97/68/EC: 69.3 kW 93 hp |
|||
|---|---|---|---|---|
| Rated PTO power (hp SAE) | At 2400 rpm per SAE: 59 kW 79 hp |
|||
| Maximum PTO power | ||||
| Power boost | ||||
| Engine peak torque | ||||
| PTO torque rise | ||||
| Intelligent Power Management (available in transport and/or mobile PTO applications) | ||||
| Maximum engine power |
Transmission
| Type | Standard: 12F/12R PowrReverser Optional: 24F/24R PowrReverser |
|||
|---|---|---|---|---|
| Reverser | Yes (hydraulic) | |||
| Clutch; wet/dry | Wet | |||
| Creeper | Optional 16F/16R |
Hydraulic system
| Type | Open Center | |||
|---|---|---|---|---|
| Pump rated output | Standard: 94.6 L/min 25 gpm |
|||
| Available flow at a single rear SCV | ||||
| Available flow at front SCVs | ||||
| Number of rear selective control valves (SCVs) | ||||
| Number of mid selective control valves (SCVs) | ||||
| Number of front selective control valves (SCVs) | ||||
| Joystick SCV control | Optional | |||
| SCV control |
Rear hitch
| Hitch draft control load sense type | Mechanical | |||
|---|---|---|---|---|
| Remote control valves available | Standard:2 Optional: 3 |
|||
| Hitch category (SAE designation) | Category 2/1/1N | |||
| Maximum lift capacity behind lift points | Standard: 1530 kg 3374 lb |
|||
| Sensing type | Top link | |||
| Rear axle differential lock | ||||
| Lift capacity at standard frame |
Drawbar
| Drawbar category | ||||
|---|---|---|---|---|
| Maximum vertical load |
Rear power take-off (PTO)
| Type | Standard: Independent 540/540 Economy (shiftable) | |||
|---|---|---|---|---|
| Engine rpm (at rated PTO speeds) | ||||
| PTO actuation | Electrohydraulic | |||
| Ground speed PTO option availability | ||||
| Multispeed PTO option availability |
Front hitch
| Category | ||||
|---|---|---|---|---|
| Electric power | ||||
| Standard lift capacity | ||||
| Front power take-off (PTO) | ||||
| PTO speed |
Rear axle
| Type | ||||
|---|---|---|---|---|
| Final drive type | Inboard planetary | |||
| Differential controls | Mechanical foot pedal | |||
| Axle type | Flanged | |||
| Brakes, type and control | Hydraulic wet disc | |||
| Rear differential lock | ||||
| Load rating |
Front axle
| Type | ||||
|---|---|---|---|---|
| Front axle differential lock | ||||
| Load rating |
Tires
| Front | 2WD: 6.5-16 6PR F2 MFWD: 8.3-16 6PR R1 |
|||
|---|---|---|---|---|
| Rear | 2WD: 12.4-24 6PR R1 MFWD: 12.4-24 6PR R1 |
|||
| Wheel tread range | 2WD: front: 1039-1439 mm 40.9-56.7 in. rear:898-1497 mm 35.4-58.9 MFWD: front: 1078-1208 mm |
|||
| Turning radius with brakes | 2WD: 3.4 m 11.1 ft MFWD: 3.53 m 11.58 ft, in. |
|||
| Turning radius without brakes | 2WD: 3.91 m 12.83 ft MFWD: 4.36 m 14.3 ft |
Steering
| Type |
|---|
Electrical system
| Alternator size | ||||
|---|---|---|---|---|
| Battery options | ||||
| Total cold cranking amps | ||||
| Type of bulb in beacon (Halogen, Zenon, LED) | ||||
| Type of bulb in headlight (Halogen, Zenon, LED) | ||||
| Working lights | ||||
| dB(A) rating for backup alarm |
Operator station
| Rollover protective structure, OOS | Rigid - foldable - telescopic Foldable, 2-post Platform - flat/straddle Straddle Gearshift location - console/floor Floor |
|||
|---|---|---|---|---|
| Seat | ||||
| Cab suspension | ||||
| Instructional seat | ||||
| Display | ||||
| Radio | ||||
| Inner cab volume | ||||
| dB(A) rating | ||||
| Cab glass area | ||||
| Front visibility | ||||
| Safety glass rating |
Dimensions
| Wheelbase | 2WD and MFWD: 2177 mm 85.7 in. |
|||
|---|---|---|---|---|
| Overall length | ||||
| Drawbar clearance | ||||
| Front axle center | ||||
| Approximate shipping weight, Open;Cab | 2WD: Open: 2487 kg 5483 lb Cab: 2550 kg 5622 lb MFWD: Open: 2560 kg 5645 lb Cab: 2624 kg 5784 lb |
|||
| Overall height |
Weight
| Base machine weight | ||||
|---|---|---|---|---|
| Maximum ballast level | ||||
| Maximum permissible weight |
Capacities
| Crankcase oil volume | ||||
|---|---|---|---|---|
| Fuel tank | Standard: 71.9 L 19 U.S. gal. |
|||
| Diesel exhaust fluid (DEF) tank | ||||
| Cooling system | ||||
| Transmission-hydraulic system |
Serviceability
| Interval for engine oil change | ||||
|---|---|---|---|---|
| Interval for hydraulic/transmission oil change | ||||
| Interval for engine coolant change |
Loaders
| Loader | ||||
|---|---|---|---|---|
| Lift capacity at full height | ||||
| Maximum lift height |
Precision AG
| Guidance | ||||
|---|---|---|---|---|
| Telematic | ||||
| Remote diagnostics |
Miscellaneous
| Country of manufacture | Augusta, GA | |||
|---|---|---|---|---|
| Side slope rating | ||||
| Uphill/downhill slope rating |
Additional information
| Date collected |
|---|
Tracks
| Drive type | ||||
|---|---|---|---|---|
| Midrollers | ||||
| Track width | ||||
| Tread spacing |
