Optional accessories and attachments shown. See your dealer for available models, options, attachments and pricing. Product options and accessories may not be available in all regions.
Zero ash-service intervals. Zero regenerations. Extremely efficient combustion allows Isuzu® engines to burn particulate matter in cylinder during combustion. Diesel exhaust fluid is injected into the exhaust stream and through Selective Catalytic Reduction (SCR), emissions standards are achieved.
Pumps 1 and 2 combined control the boom and arm functions. Pump 3 is dedicated to swing. The result is fast cycle times and increased productivity.
Take digging forces to new levels with power boost when you need it. This machine is a well-balanced, smooth operating machine in a reduced tailswing configuration.
Factory installed auxiliary hydraulic lines enable your excavator to run a number of attachments and increase the versatility of your machine, without the need for additional machines or operators.
Optional Right Rear and Left Camera system with additional light-emitting diode (LED) surround lighting work together to provide the operator enhanced 270 degree visibility around the machine. All integrated into the main monitor.
|Specs & Compare|
|Select up to 4 models to compare specifications||
|Emission Rating||Tier 4 / Stage IV|
|Number Of Cylinders||6|
|Displacement, ltr (Inches³)||7.8 (475)|
|Rated speed, rpm||1900|
|Engine Output - Net, kW (hp)||186 (249)|
|Number Of Carrier Rollers - Each Side||2|
|Number Of Track Rollers - Each Side||8|
|Track Shoe Width, mm (inches)||800 (32)|
|Transport Length Mono Boom, mm (ft/in)||10020 (32 ft 10 in)|
|Transport Height - Maximum, mm (ft/in)||3420 (11 ft 3 in)|
|Overall Undercarriage Width, mm (ft/in)||3390 (11 ft 1 in)|
|Track Length On Ground, mm (ft/in)||4050 (13 ft 3 in)|
|Overall Undercarriage Length, mm (ft/in)||4940 (16 ft 2 in)|
|Tailswing Radius, mm (ft/in)||2090 (6 ft 10 in)|
|Ground Clearance, mm (inches)||500 (20)|
|Width over fixed tracks, mm (ft/in)||3390 (11 ft 1 in)|
|Track Gauge, mm (ft/in)||2590 (8 ft 6 in)|
|Digging Reach - Mono Boom, mm (ft/in)||11460 (37 ft 7 in)|
|Ground Level Reach - Mono Boom, mm (ft/in)||11220 (36 ft 10 in)|
|Dig Height - Mono Boom, mm (ft/in)||11690 (38 ft 4 in)|
|Dump Height - Mono Boom, mm (ft/in)||8670 (28 ft 5 in)|
|Dig depth - 2.44m / 8'ft flat bottom, mm (ft/in)||7410 (24 ft 4 in)|
|Dig Depth - Mono Boom, mm (ft/in)||7570 (24 ft 10 in)|
|Fuel Tank, ltr (gallons (US))||380 (100)|
|Hydraulic Tank, ltr (gallons (US))||160 (42)|
|Ground Bearing Pressure, kPa (PSI)||50 (7.3)|
|Swing Speed, rpm||10.5|
|Swing Torque, kNm (lbf / ft)||90.5 (66750)|
|Travel Speed - High, kph (mph)||4.1 (2.5)|
|Tractive Force, kN (lbf)||298 (66990)|
|Arm Tearout, kN (lbf)||127 (28550)|
|Bucket Breakout, kN (lbf)||202 (45410)|
|End lift - 7.5m Reach, kg (lbs)||9220 (19870)|
|Side lift - 7.5m Reach, kg (lbs)||5450 (11770)|
|Total Flow, lt/min (gallons (US) / min)||681 (180)|
|Bucket Pressure, bar (PSI)||343 (4970)|
|Boost Pressure, bar (PSI)||380 (5510)|
|Operating Weight, kg (lbs)||35700 (78705)|
Get more work done more efficiently through our suite of precision construction solutions.
Stay up and running and lower your costs by making the most of our world-class dealer network.
You need a finance team that gets in the trenches to learn about your entire operation – not just your credit score.
Features and specifications are based on published information at the time of publication. Features and specifications are subject to change without notice.
