Optional accessories and attachments shown. See your dealer for available models, options, attachments and pricing. Product options and accessories may not be available in all regions.
P-Tier updates build on the proven G-Series design. Take front joint durability to new levels compared to G-Series.
Factory installed hydraulic plumbing all the way to the end of the arm. Coupler controls integrated into a switch in the cab. Quick and efficient coupler installation. Popular in the underground segment, couplers allow excavators to efficiently switch attachments and get more productive working hours each day.
|Specs & Compare|
|Select up to 4 models to compare specifications||
|Emission Rating||Tier 4 / Stage IV|
|Engine Manufacturer||John Deere Power Tech|
|Number Of Cylinders||4|
|Displacement, ltr (Inches³)||4.5 (275)|
|Rated speed, rpm||2000|
|Engine Output - Net, kW (hp)||109 (146)|
|Number Of Carrier Rollers - Each Side||2|
|Number Of Track Rollers - Each Side||7|
|Track Shoe Width, mm (inches)||800 (32)|
|Transport Length Mono Boom, mm (ft/in)||9040 (29 ft 8 in)|
|Transport Height - Maximum, mm (ft/in)||3390 (11 ft 1 in)|
|Overall Undercarriage Width, mm (ft/in)||3000 (9 ft 10 in)|
|Track Length On Ground, mm (ft/in)||3370 (11 ft 1 in)|
|Overall Undercarriage Length, mm (ft/in)||4170 (13 ft 8 in)|
|Tailswing Radius, mm (ft/in)||2550 (8 ft 4 in)|
|Ground Clearance, mm (inches)||450 (18)|
|Width over fixed tracks, mm (ft/in)||3000 (9 ft 10 in)|
|Track Gauge, mm (ft/in)||2200 (7 ft 3 in)|
|Digging Reach - Mono Boom, mm (ft/in)||9940 (32 ft 7 in)|
|Ground Level Reach - Mono Boom, mm (ft/in)||9790 (32 ft 1 in)|
|Dig Height - Mono Boom, mm (ft/in)||9790 (32 ft 1 in)|
|Dump Height - Mono Boom, mm (ft/in)||6930 (22 ft 9 in)|
|Dig depth - 2.44m / 8'ft flat bottom, mm (ft/in)||6870 (22 ft 6 in)|
|Dig Depth - Mono Boom, mm (ft/in)||7070 (23 ft 2 in)|
|Fuel Tank, ltr (gallons (US))||285 (75.3)|
|Hydraulic Tank, ltr (gallons (US))||125 (33)|
|Ground Bearing Pressure, kPa (PSI)||32 (4.64)|
|Swing Speed, rpm||12.8|
|Swing Torque, kNm (lbf / ft)||50 (36765)|
|Travel Speed - High, kph (mph)||5.3 (3.3)|
|Tractive Force, kN (lbf)||169 (38030)|
|Arm Tearout, kN (lbf)||83.7 (18825)|
|Bucket Breakout, kN (lbf)||127 (28552)|
|End lift - 7.5m Reach, kg (lbs)||4370 (9420)|
|Side lift - 7.5m Reach, kg (lbs)||2830 (6110)|
|Total Flow, lt/min (gallons (US) / min)||382 (100)|
|Bucket Pressure, bar (PSI)||343 (4980)|
|Boost Pressure, bar (PSI)||380 (5511)|
|Operating Weight, kg (lbs)||20507 (45170)|
