Frontier™ Tillage Equipment

aerial view of tractor pulling tillage attachment in field

Turn Your Tractor Into The Workhorse it was Built to Be

Frontier™ Tillage Equipment delivers the size, options, adjustability, and affordability your operation needs.

Eliminate standing water. Rip tree roots along a fence line so your pasture isn't deprived of precious water. Break up tough, compacted soil, giving your garden or crop a chance to really grow.

  • Heat-treated steel shanks
  • Replaceable wear tips
  • Shank spacing is adjustable (SR1203 only)
  • iMatchTM and Quick Hitch compatible (iMatchTM compatible SR1201 only)

ModelNumber of ShanksWorking DepthPTO HPHitch

1

14 - 18 in. (35.6 - 45.7 cm)

25 - 60 hp (18.6 - 44.7 kW)

Cat. 1 and 2

2

14 - 18 in. (35.6 - 45.7 cm)

50 - 110 hp (37.2 - 82 kW)

Cat. 2

3

14 - 18 in. (35.6 - 45.7 cm)

75 - 110 hp (55.9 - 82 kW)

Cat. 2

Maximize yield with a well-prepared seedbed and great seed-to-soil contact. Great for use by property owners, landscapers, and smaller producers.

  • iMatchTM and/or Quick Hitch compatible
  • Heavy duty steel square tube mainframe
  • Available in 4’, 6’, 8’, and 12’ working widths
  • 9.5 in or 16 in cast iron packer wheels

ModelRow WidthPTO HPHitch

48 in. (121.9 cm)

20 - 40 hp (14.9 - 29.8 kW)

Limited Cat. 1

72 in. (182.9 cm)

20 - 40 hp (14.9 - 29.8 kW)

Limited Cat. 1

72 in. (182.9 cm)

30 - 70 hp (22.4 - 52.2 kW)

Cat. 1

96 in. (243.8 cm)

30 - 125 hp (22.4 - 93.2 kW)

Cat. 1 and Cat. 2

144 in. (365.8 cm)

75 - 125 hp (55.9 - 93.2 kW)

Cat. 2

When it’s time to work your land, Frontier Disks are built to handle a variety of unpredictable soil conditions.
· Notched or spherical blades available for aggressive or smooth cutting
· Adjustable front-to-rear leveling

ModelWorking Width/Front-Rear Blade SpacingPTO HPHitch

4 ft. (1.2 m)/ 7.5 in. (19.1 cm) space1

14 – 28 hp (10.4 – 20.9 kW)

3-Pt./Cat.12

5 ft. 6 in. (1.7 m)/ 7.5 in. (19.1 cm) space1

14 – 28 hp (10.4 – 20.9 kW)

3-Pt./Cat.12

5 ft. 6 in. (1.7 m)/ 7.5 in. (19.1 cm) space1

22 – 45 hp (16.4 – 33.6 kW)

3-Pt./Cat.12

6 ft. 4 in. (1.9 m)/9 in. (22.9 cm) space1

22 – 45 hp (16.4 – 33.6 kW)

3-Pt./Cat.12

6 ft. 8 in. (2.0 m)/7.5 in. (19.1 cm) space1

22 – 45 hp (16.4 – 33.6 kW)

3-Pt./Cat.12

6 ft. 4 in. (1.9 m)/9 in. (22.9 cm) space1

30 – 55 hp (22.4 – 41.0 kW)

3-Pt./Cat.12

6 ft. 8 in. (2.0 m)/7.5 in. (19.1 cm) space

30 – 55 hp (22.4 – 41.0 kW)

3-Pt./Cat.12

8 ft. (2.4 m)/ 7.5 in. (19.1 cm) space1

30 – 55 hp (22.4 – 41.0 kW)

3-Pt./Cat.12

8 ft. (2.4 m)/ 9 in. (22.9 cm) space1

30 – 55 hp (22.4 – 41.0 kW)

3-Pt./Cat.12

6 ft. 4 in. (1.9 m)/9 in. (22.9 cm) space1

40 – 75 hp (25.8 – 55.9 kW)

3-Pt./Cat. 1 and 22

6 ft. 8 in. (2.0 m)/7.5 in. (19.1 cm) space

40 – 75 hp (25.8 – 55.9 kW)

3-Pt./Cat. 1 and 22

8 ft. (2.4 m)/ 7.5 in. (19.1 cm) space1

40 – 75 hp (25.8 – 55.9 kW)

3-Pt./Cat. 1 and 22

8 ft. (2.4 m)/ 9 in. (22.9 cm) space1

40 – 75 hp (25.8 – 55.9 kW)

3-Pt./Cat. 1 and 22

8 ft. (2.4 m)/ 7.5 in. (19.1 cm) space1

35 – 55 hp (26.1 – 41.0 kW)

Drawn/Clevis

8 ft. (2.4 m)/ 9 in. (22.9 cm) space1

35 – 55 hp (26.1 – 41.0 kW)

Drawn/Clevis

8 ft. (2.4 m)/ 9 in. (22.9 cm)/ 7.5 in. (19.1 cm) space

35 – 55 hp (26.1 – 41.0 kW)

Drawn/Clevis

9 ft. 6 in. (2.9 m)/ 7.5 in. (19.1 cm) space1

40 – 65 hp (29.8 – 40.5 kW)

Drawn/Clevis

9 ft. 6 in. ((2.9 m)/ 9 in. (22.9 cm) space1

40 – 65 hp (29.8 – 40.5 kW)

Drawn/Clevis

9 ft. 6 in. (2.9 m)/ 9 in. (22.9 cm)/ 7.5 in. (19.1 cm) space

40 – 65 hp (29.8 – 40.5 kW)

Drawn/Clevis

10 ft. 6 in. (3.2 m)/ 7.5 in. (19.1 cm) space1

45 – 75 hp (33.6 – 55.9 kW)

Drawn/Clevis

10 ft. 6 in. (3.2 m)/ 9 in. (22.9 cm) space1

45 – 75 hp (33.6 – 55.9 kW)

Drawn/Clevis

10 ft. 6 in. (3.2 m)/9 in. (22.9 cm)/ 7.5 in. (19.1 cm) space

45 – 75 hp (33.6 – 55.9 kW)

Drawn/Clevis

12 ft. (3.7 m)/ 7.5 in. (19.1 cm) space1

55 – 85 hp (41.0 – 59.7 kW)

Drawn/Clevis

12 ft. (3.7 m)/ 9 in. (22.9 cm) space1

55 – 85 hp (41.0 – 59.7 kW)

Drawn/Clevis

12 ft. (3.7 M)/9 in. (22.9 cm)/ 7.5 in. (19.1 cm) space

55 – 85 hp (41.0 – 59.7 kW)

Drawn/Clevis

10 ft. 6 in. (3.2 m)/ 9 in. (22.9 cm) space1

60 – 80 hp (44.7 – 59.7 kW)

Drawn/Clevis

12 ft. (3.7 m)/ 9 in. (22.9 cm) space1

75 – 125 hp (55.9 – 93.2 kW)

Drawn/Clevis

13 ft. 6 in. (4.1 m)/ 9 in. (22.9 cm) space1

75 – 125 hp (55.9 – 93.2 kW)

Drawn/Clevis

15 ft. (4.6 m)/ 9 in. (22.9 cm) space1

80 – 140 hp (59.7 – 104.4 kW)

Drawn/Clevis

1Front and rear spacing identical 2iMatch and/or Quick-Coupler compatible.

Your land may be tough, but 3-Point Offset Disks are even tougher. As many as 24 notched disk blades enable you to level, cut, and mix soil to full working depth, all in one pass.
·High strength for adverse conditions
·Adjustable front and rear gang angles
·Optional adjustable blade scrapers for working in wet, sticky soil
·iMatch™ and/or Quick-Coupler compatible

ModelWorking WidthPTO HPHitch

5 ft. 3 in. (1.6 m)

30 - 75 hp (22.4 - 55.9 kW)

3-Pt. / Cat. 1 and 2

6 ft. (1.8 m)

30 - 75 hp (22.4 - 55.9 kW)

3-Pt. / Cat. 1 and 2

6 ft. 8 in. (2.0 m)

30 - 75 hp (22.4 - 55.9 kW)

3-Pt. / Cat. 1 and 2

7 ft. 6 in. (2.3 m)

45 - 75 hp (33.6 - 55.9 kW)

3-Pt. / Cat. 1 and 2

8 ft. 4 in. (2.5 m)

45 - 75 hp (33.6 - 55.9 kW)

3-Pt. / Cat. 1 and 2

6 ft. 2 in. (1.9 m)

60 - 130 hp (44.7 - 96.9 kW)

3-Pt. / Cat. 2 and 3

6 ft. 8 in. (2.0 m)

60 - 130 hp (44.7 - 96.9 kW)

3-Pt. / Cat. 2 and 3

7 ft. 6 in. (2.3 m)

60 - 130 hp (44.7 - 96.9 kW)

3-Pt. / Cat. 2 and 3

8 ft. 4 in. (2.5 m)

60 - 130 hp (44.7 - 96.9 kW)

3-Pt. / Cat. 2 and 3

9 ft. (2.7 m)

60 - 130 hp (44.7 - 96.9 kW)

3-Pt. / Cat. 2 and 3

Put the final touches on gardens or seedbeds before planting with a Rotary Tiller.
·"C" and/or "L" shaped blades, depending on model
·Helical-shaped rotors
·All models offer skid shoes for depth control
·iMatch™ and/or Quick-Coupler compatible

ModelDuty / WidthPTO HPHitch

Standard / 42 in. (106.7 cm)

15 - 25 hp (11.2 - 18.6 kW)

3-Pt. / Cat. 0 and 1

Standard / 49 in. (124.5 cm)

20 - 25 hp (14.9 - 18.6 kW)

3-Pt. / Cat. 1

Standard / 57 in. (144.8 cm)

25 - 40 hp (18.6 - 29.8 kW)

3-Pt. / Cat. 1 and 2

Standard / 65 in. (165.1 cm)

30 - 40 hp (22.4 - 29.8 kW)

3-Pt. / Cat. 1 and 2

Standard / 73 in. (185.4 cm)

45 - 60 hp (33.6 - 44.7 kW)

3-Pt. / Cat. 1 and 2

Standard / 81 in. (205.7 cm)

50 - 60 hp (37.3 - 44.7 kW)

3-Pt. / Cat. 2

Medium / 65 in. (165.1 cm)

30 - 60 hp (22.4 - 44.7 kW)

3-Pt. / Cat. 1 and 2

Medium / 73 in. (185.4 cm)

50 - 80 hp (37.3 - 59.7 kW)

3-Pt. / Cat. 2

Medium / 83 in. (210.8 cm)

60 - 100 hp (44.7 - 74.6 kW)

3-Pt. / Cat. 2

Medium / 93 in. (236.2 cm)

70 - 100 hp (52.2 - 74.6 kW)

3-Pt. / Cat. 2

Heavy Duty / 83 in. (210.8 cm)

80 - 130 hp (59.7 - 96.9 kW)

3-Pt. / Cat. 2

Heavy Duty / 102 in. (259.1 cm)

80 - 130 hp (59.7 - 96.9 kW)

3-Pt. / Cat. 2

Heavy Duty / 121 in. (307.3 cm)

100 - 130 hp (74.6 - 96.9 kW)

3-Pt. / Cat. 2

Control weeds with the One-Row Cultivator. Adjustable row widths make this tool valuable for gardeners and small farm operators.
·Six cultivator tines with 1.75 in. x 10 in. (4.5 cm x 25.4 cm) long reversible curved points
·Tine spacing is adjustable

ModelRow WidthPTO HPHitch

30 - 60 in. (76.2 - 152.4 cm)

18 - 45 hp (13.4 - 33.6 kW)

3-Pt. / Cat. 1

Prepare seedbeds, mix crop residue into soil, and blend soil to provide water and nutrients to crops with a versatile Field Cultivator.
·13 S-tines with optional tillage points for unsurpassed tillage action
·John Deere Parts offers optional shovels, sold separately
·iMatch™ compatible

ModelWorking WidthPTO HPHitch

72 in. (182.9 cm)

18 - 45 hp (13.4 - 33.6 kW)

3-Pt. / Cat. 1

Seedbed preparation is a snap with Mulch Finishers. Choose from 6-, 8- or 12-disk blades to break through hard, layered soil.
·Vibrating S-tines ensure uniform tillage depth
·Three ground-management points are available. 9 in. (22.9 cm) sweeps are standard. Chisel spikes, and turning tips are available through John Deere Service Parts
·Level seedbeds with an optional rolling basket
·iMatch™ and/or Quick-Coupler compatible

ModelWorking WidthPTO HPHitch

42 in. (106.7 cm)

30 - 50 hp (22.4 - 37.3 kW)

3-Pt. / Cat. 1

60 in. (152.4 cm)

45 - 75 hp (33.6 - 55.9 kW)

3-Pt. / Cat. 1 and 2

82 in. (208.3 cm)

60 - 100 hp (44.7 - 74.6 kW)

3-Pt. / Cat. 1 and 2

Break up hard ground between garden rows with a convenient Middle Buster with a 15 x 11 in. (38.1 x 27.9 cm) double-wing cutting blade.
·Dig furrows for planting vegetables, digging potatoes or knocking out other small gardening chores
·iMatch™ compatible

ModelWorking DepthPTO HPHitch

Up to 12 in. (30.5 cm)

18 - 45 hp (13.4 - 33.6 kW)

3-Pt. / Cat. 1

Get higher yields from your garden with the handy Subsoiler. Featuring a 1 x 6 in. (2.5 x 15.2 cm) steel shank with reversible hitch point, this small tillage tool rips through hard ground to break up compaction, improving water drainage, and root growth.
·Standard duty for lower horsepower models

ModelWorking DepthPTO HPHitch

Up to 24 in. (61.0 cm)

18 - 45 hp (13.4 - 33.6 kW)

3-Pt. / Cat. 1

Prepare garden space or planting areas with One- and Two-Bottom Plows. Our 3-Point Plows allow you to turn over sod in your field or backyard.
·14 in. (35.6 cm) or 40 in. (101.6 cm) moldboard width)
·Replaceable plow shares, shins, and landslides

ModelMoldboard WidthPTO HPHitch

One - Bottom / 14 in. (35.6 cm)

25 -50 hp (13.4 - 37.3 kW)

3-Pt. / Cat. 1

Two - Bottom / 40 in. (101.6 cm)

25 - 50 hp (13.4 - 37.3 kW)

3-Pt. / Cat. 1

The Frontier™ VT17 Series Vertical Tillage tools provide speed, versatility, and residue management performance for growers.

  • Adjustable gang angles for desired aggressiveness
  • Simple adjustments for increased uptime
  • Rolling baskets and blade options enable a smooth field finish

ModelWorking WidthPTO HPHitch

10 ft. 6 in. (3.2 m)

70 – 90 hp (51.5 – 66.2 kW)

Drawn/Clevis

13 ft. 8 in. (4.2 m)

80 – 100 hp (58.8 – 73.6 kW)

Drawn/Clevis

14 ft. 8 in. (4.5 m)

90 – 110 hp (66.2 – 91 kW)

Drawn/Clevis

16 ft. 6 in. (5 m)

101 – 125 hp (74.3 – 92 kW)

Drawn/Clevis
