LP21 Series

Features

Skid shoes are adjustable up and down

Skid shoes increase the life of the cutting edges on the land planes while avoiding damage to the working surface.

The skid shoes are adjustable up and down on each side plate to allow for the creation of a crown on a road for water runoff.

By replacing the skid shoes when needed, it will extend the life of the land plane.

Adjustable for different types of groundwork scarifier shanks shown engaged

Adjustable shanks

The scarifier shanks can be easily adjusted for depth control.

Specifications

Specifications

John Deere

LP21 Series

Land Planes

1 2

Working width	LP2054L: 137.2 cm 54 in. LP2160: 152.4 cm 60 in. LP2172: 182.9 cm 72 in. LP2184: 213.4 cm 84 LP2196: 243.8 cm 96
Overall Width	LP2054L: 147.3 cm 58 in. LP2160: 165.1 cm 65 in. LP2172: 193.0 cm 76 in. LP2184: 223.5 cm 88 in. LP2196: 254.0 cm 100 in.
Overall Height	LP2054L: 83.8 cm 33 in. LP2160: 88.9 cm 35 in. LP2172: 88.9 cm LP2184: 88.9 cm LP2196: 88.9 cm
Overall Length	LP2054L: 121.9 cm 48 in. LP2160: 121.9 cm LP2172: 121.9 cm LP2184: 137.2 cm 54 in. LP2196: 137.2 cm
Height to Hitch Pins	LP2054L: 35.6 cm 14 in. LP2160: 40.6 cm 16 in. LP2172: 40.6 cm LP2184: 40.6 cm LP2196: 40.6 cm

Operating	LP2054L: 143.3 kg 316 lb LP2160: 219.5 kg 484 lb LP2172: 239.5 kg 528 lb LP2184: 276.7 kg 610 lb LP2196: 296.2 kg 653 lb
Shipping	LP2054L: 308.4 kg 680 lb LP2160: 461.8 kg 1018 lb LP2172: 501.7 kg 1106 lb LP2184: 553.4 kg 1220 lb LP2196: 615.1 kg 1356 lb
Implement code

Required PTO horsepower	LP2054L: 13.4-22.4 kW 18-30 hp LP2160: 18.6-37.3 kW 25-50 hp LP2172: 18.6-37.3 kW LP2184: 29.8-67.1 kW 40-90 hp LP2196: 29.8-67.1 kW

Style	All:Clevis w/ Pin
3-point compatibility	LP2054L: Cat 1 Limited LP2160: Cat 1 LP2172: Cat 1 LP2184: Cat 1 and 2 LP2196: Cat 1 and 2
iMatch™ compatible (Cat. 1)
Quick-coupler compatible (Cat. 2)	All:Yes
Pull-type

Type	All:High Carbon Heat Treated Blades
Reversible	All:Yes
Replaceable	All:Yes
Quantity	All:Two
Size, in. (cm)	All:0.95x15.2 cm 0.375x6 in.
Placement	All:Blades Positioned at a 10 Degree Angle

Configuration	All: Infinitely adjustable
Thickness	LP2054L: 0.635 cm 0.25 in. LP2160: 0.95 cm 0.375 in. LP2172: 0.95 cm LP2184: 0.95 cm LP2196: 0.95 cm
Height adjustment range	All:6.35 cm 2.5 in.

Configuration	All:One unit

Labor hours

Time period	All:1 year

Adjustable	LP2054L: 3 Position LP2160: 4 Position LP2172: 4 Position LP2184: 4 Position LP2196: 4 Position
Heat treated	All:Yes
Available
Points
Quantity	LP2054L: 4 LP2160: 4 LP2172: 5 LP2184: 6 LP2196: 7
Tubular scarifier beam size
Tubular scarifier beam thickness
Scarifier Depth Range	LP2054L: 0 cm 0 in. , -3.81 cm -1.5 in., -7.62 cm -3 in. LP2160: 5.08 cm 2 in. , 0 cm 0 in. , -5.08 cm -2 in. , -10.16cm -4 in. LP2172: 5.08 cm 2 in. , 0 cm 0 in. , -5.08 cm -2 in. , -10.16cm -4 in. LP2184: 5.08 cm 2 in. , 0 cm 0 in. , -5.08 cm -2 in. , -10.16cm -4 in. LP2196: 5.08 cm 2 in. , 0 cm 0 in. , -5.08 cm -2 in. , -10.16cm -4 in.
